Revopoint Mini 2 Precision 3D Scanner
On this page you can purchase the Revopoint Mini 2 3D scanner, a next-generation 3D scanner utilising industrial-grade blue light. The Mini 2 delivers metrological precision of up to 0.02 mm, thanks to its powerful hardware. It is optimised to capture every minute detail for quality control, personalised healthcare solutions, artistic design, 3D modelling, and many other applications.
Key Features
- Industrial-grade blue light.
- 3D Scanning speed of 16 fps.
- Metrological 3D Scanning precision of up to 0.02 mm.
- High-speed data transfer via Wi-Fi 6 and USB Type-C.
- 9-axis IMU.
- Large single-frame capture area.
Metrological Precision
Create reliable digital copies of complex parts with repeatable precision of up to 0.02 mm. Thanks to ultra-high-resolution blue light technology, the MINI 2 scans objects with an accuracy of up to 0.05 mm.
Fast Mode
Get your projects started quickly, producing ultra-detailed 3D models in a matter of seconds — thanks to the MINI 2's high 3D Scanning speed of up to 16 frames per second.
Unified Colour Scanning
Capture sharper, more consistent colour scans with the MINI 2's new higher-resolution RGB camera and LED flashes for uniform object illumination and shadow elimination.
Depth of up to 2 megapixels / RGB camera resolution.
Flexible Working Distance
Working distance of 120 – 250 mm.
9-Axis IMU with Anti-Vibration Protection
- Elimination of defective frames caused by vibration or rapid movement.
- CPU: 2 cores at 1.8 GHz.
- Position sensors: 9-axis IMU.
Fast Connectivity and Stable Scanning
Achieve lower latency and more stable mobile scanning thanks to the MINI 2's new Wi-Fi 6 connection and Plug and Play setup via USB Type-C.
Specifications
| Light Source | Structured blue light + white LED flashes |
| Scanning Range (mm) | 64 × 52 at 120 mm distance, 168 × 132 at 250 mm distance |
| Working Distance (mm) | 120 – 250 |
| Scanner Type | Handheld |
| Additional Extensions | No |
| Colour Scanning | Yes |
| Marker Scanning | Yes |
| Scanning Mode | Manual, turntable |
| Technology | Structured blue light with dual camera |
| Safety Class | Class 1 Blue Light |
| Processor | 2 cores at 1.8 GHz |
| Part Size Range (m) | min. 0.01 × 0.01 × 0.01 |
| Scanning Speed (frames/s) | Up to 16 |
| Scanning Precision (mm) | Up to 0.02 |
| Scanning Accuracy (mm) | Up to 0.050 |
| Colour Reproduction | RGB Camera |
| Camera Resolution (pixels) | 2 MP |
| Point Distance (mm) | Up to 0.02 |
| Position Sensors | 9-axis IMU |
| Positioning Methods | Feature-based, marker-based |
| Special Features | 3D printing compatibility. Use scanning spray for transparent, dark, or highly reflective objects. Not suitable for outdoor scanning. |
| Supported File Types | PLY, OBJ, STL |
| Connectivity | Wi-Fi 6, USB Type-C |
| System Requirements | Windows 10/11 (64-bit), Android, iOS, macOS |
| Country of Manufacture | China |
| Warranty Period (months) | 12 |
| Net Weight (kg) | 0.175 |
| Net Dimensions (mm) | 132 × 53 × 36 |
